Hydraulic loading dock lift tables are generally used for occasional transhipments of various heights and types of vehicle. They can handle both very low vehicles (small rigids, vans) and very high vehicles (semi-trailers and containers). A platform lift also enables handling equipment to be lowered and raised from the platform to the ground.

Hydraulic loading dock lift table

Capacity from 1000 to 8000 kg

Hydraulic loading dock lift table Expresso

Hydraulic loading dock lift table Expresso

This hydraulic loading dock lift table is ideal for occasional transshipments with differents heights and various types of vehicles

Floor-mounted with or without flush-mounting

Robust steel construction

Single pantograph

Tray in reinforced sheet metal

Single-acting cylinders with parachute

Aluminium safety perimeter

Loading by pallet truck or forklift depending on model

24 volt sustained pressure up-down control box

Reset button: for use in the event of intrusion into the security perimeter

Yellow and black side safety strips

Options:

Column-mounted control box

Additional pedals

Retractable stop

Loading ramps

Lateral safety barrier

Dock bumpers

Hydraulic loading dock lift table Expresso

Hydraulic loading dock lift table reference

Capacity

1 000 kg

1 000 kg

1 000 kg

2 000 kg

2 000 kg

2 000 kg

2 000 kg

3 000 kg

3 000 kg

3 000 kg

3 000 kg

4 000 kg

4 000 kg

4 000 kg

4 000 kg

4 000 kg

6 000 kg

6 000 kg

6 000 kg

8 000 kg

8 000 kg

8 000 kg

Lifting height

1 600 mm

1 980 mm

1 980 mm

1 600 mm

1 600 mm

1 980 mm

1 980 mm

1 600 mm

1 600 mm

1 980 mm

1 980 mm

1 600 mm

1 600 mm

1 800 mm

1 800 mm

1 800 mm

1 800 mm

1 800 mm

1 800 mm

1 800 mm

1 800 mm

1 800 mm

Collapsed height

350 mm

350 mm

350 mm

350 mm

350 mm

350 mm

350 mm

380 mm

380 mm

380 mm

380 mm

500 mm

500 mm

550 mm

550 mm

550 mm

600 mm

600 mm

600 mm

650 mm

650 mm

650 mm

Platform L x w

2500 x 1200 mm

3000 x 1500 mm

3000 x 2000 mm

2500 x 1500 mm

2500 x 2000 mm

3000 x 1500 mm

3000 x 2000 mm

2500 x 1500 mm

3000 x 2000 mm

2500 x 1500 mm

2500 x 2000 mm

3000 x 1500 mm

3000 x 2000 mm

2500 x 2000 mm

3000 x 2000 mm

2500 x 1500 mm

3000 x 2000 mm

3000 x 2400 mm

3500 x 2400 mm

3000 x 2000 mm

3000 x 2400 mm

3500 x 2400 mm

Lifting time

34 sec

45 sec

45 sec

34 sec

34 sec

45 sec

45 sec

35 sec

35 sec

50 sec

50 sec

30 sec

30 sec

36 sec

36 sec

36 sec

42 sec

42 sec

42 sec

50 sec

50 sec

50 sec

Motor power

3 kw

3 kw

3 kw

3 kw

3 kw

3 kw

3 kw

3 kw

3 kw

4 kw

4 kw

4 kw

4 kw

4 kw

4 kw

4 kw

4 kw

4 kw

4 kw

4 kw

4 kw

4 kw
